• RN25-A1
• RN25-A3
• RN25-B1
• RN25-B2
• RN25-B3
|
 |
| Part Number | Mounting Hold Size | Switch Rating | Switch Combination | Operation Types | Head Shape | Enclosure Material | Degree of protection | Lamp Type | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| RD25-A1 | φ25mm | 5A/250VAC | 1NO 1NC/2NO 2NC | Resetable Self-locking | Flat | Nickel plated brass/Stainless stell | IP67,IK10 | Ring Illuminated | 暫無 |
| RD25-A3 | φ25mm | 5A/250VAC | 1NO 1NC/2NO 2NC | Resetable Self-locking | Flat | Nickel plated brass/Stainless stell | IP67,IK10 | Character Illuminated | 暫無 |
| RD25-B1 | φ25mm | 5A/250VAC | 1NO 1NC/2NO 2NC | Resetable Self-locking | High Flat | Nickel plated brass/Stainless stell | IP67,IK10 | Ring Illuminated | 暫無 |
| RD25-B2 | φ25mm | 5A/250VAC | 1NO 1NC/2NO 2NC | Resetable Self-locking | Round | Nickel plated brass/Stainless stell | IP67,IK10 | Dot Illuminated | 暫無 |
| RD25-B3 | φ25mm | 5A/250VAC | 1NO 1NC/2NO 2NC | Resetable Self-locking | High Flat | Nickel plated brass/Stainless stell | IP67,IK10 | Character Illuminated | 暫無 |
